Bullion, concentrate and product tracking
Track gold and silver bars, concentrate loads and product containers from pour or loading through to dispatch, and issue approved certificates of analysis.
The product that leaves site is where metal accounting meets revenue. Every doré bar, concentrate load or product container has to be weighed, sampled, assayed, recorded and dispatched, and the figures have to tie back to the plant. MAX tracks product as parcels, so the same system that accounts for metal in the circuit accounts for metal leaving it.
Parcels and batches, configured for your product
A parcel is one physical unit of product: a gold or silver bar, a bag, a bulk container, a truck load. Parcels are grouped into batches, such as a gravity or electrowinning pour, a smelt, or a day’s loading. What a parcel is, which measurements it carries and how it is numbered are configured for each product, so the same feature serves very different operations:
- A gold CIL plant records doré bars from each smelt with their gold and silver assays, and groups them into doré shipments.
- Another gold operation separates gravity bars and solution bars, each from their own pours.
- A base-metal operation tracks copper and zinc concentrate truck loads and shipments with nine assayed elements.
- For rare earths, the same configuration covers bags, containers and truck loads of concentrate, each assayed for individual rare earth oxides.
Each parcel records its wet mass, dry mass, moisture, volume and bulk density, and its assays for whichever elements matter, so contained metal can be calculated by the same formulas used elsewhere. Fields such as a bar number or fineness are added as the product needs them.
Approval before the figures count
Batches move through pending approval, approved or rejected, so a pour or a day’s loading is checked and signed off by the right person, and everyone can see which figures have been approved.
Transfers and custody
Parcels move: from the gold room to the vault, from the bagging plant to a stockpile, from site to a port. Each transfer records where a parcel came from and where it went, with its mass and assays at that point, and transfers that depend on one another are linked, giving a traceable record of the product’s path. Parcels and certificates can carry named signatories for the people responsible for each step.
Where a product passes between two operations that both run MAX, one site can import the other’s parcels directly, so a product dispatched from one site arrives at the next with its weights and assays already recorded.
Certificates of analysis
MAX generates certificates for a parcel, a set of transfers or several batches together, laid out with your logo and footer and numbered from a sequence you define. Certificates are drafted, approved and, if necessary, voided, so only approved certificates go to a customer or refinery, and the figures on them are the figures in MAX.
Shipments and consignments
For product shipped by sea, MAX records shipments with their ship, ports of loading and discharge, bill of lading date and signatories, and splits each shipment into consignments by consignee, with the dry and wet mass allocated to each.
Tied to the metal balance
Because parcels, transfers and inventories share one database, product leaving site appears in the metal balance and in reports alongside production, rather than in a separate register that has to be reconciled by hand.
